Sewing machine threading instruction

Brother PS-3700 Sewing Machine Threading Instructions.







Threading Instructions

* Raise the presser foot using the Presser Foot Lever. (Fig. A).

1. Raise the needle to its highest position by turning the handwheel toward you (counterclockwise). (This step will raise the thread take-up into the correct position for threading.) 1 Presser foot lever

2. Draw thread from spool through the upper thread guide. (4)

3. Place a spool of thread on the horizontal spool pin with the thread coming from the bottom front of the spool. Press a spool cap onto the spool pin to hold the thread spool firmly in place. (Fig. B)
The thread end should come from the bottom front of the spool.

4. Pass thread through upper thread path. (Fig. C)

5. Make sure to guide the thread through the thread take-up lever from the right to the left. (Fig. D) 2 Thread take-up lever

6. Place thread behind the guide on the needle clamp above the needle (Fig. E) through the opening on the right of the guide. 3 Needle clamp

NOTE:
If the thread take-up lever is lowered, the upper thread can not be placed in the thread take-up lever correctly. Be sure to raise the Presser Foot Lever and the thread take-up before threading the upper thread.
Incorrectly feeding the thread may cause sewing problems.

CAUTION: Be sure to thread the machine properly. Improper threading can cause the thread to tangle and break the needle, leading to injury.

Brother PS-3700 Sewing Machine Threading Instructions

You can find the complete instruction manual here.

White 616 Sewing Machine Threading Instructions.







Threading Instructions

1. Turn the hand wheel toward you to raise the take-up lever to its highest position.

2. Place a spool of thread on the spool pin.

3. Lead the thread through the upper arm thread guides.

4. Run the thread through the thread guide bar to the tension discs, then around and between them from right to left.

5. Draw the thread up through the check spring and with o slight tug into the hook, (See insert Fig. 12)

6. Pass the thread under the bar and up through the eye of the take-up lever from right to left.

7. Lead thread down under bar, through the face plate guides and then through the needle bar guide from the back.

8. Thread needle FROM LEFT TO RIGHT, drawing it through about 3 or 4 inches. Hold the end of the upper thread loosely and turn the. hand wheel toward you until the needle goes all the
way down and comes back up. A loop (Fig.13) will be formed over the upper thread which then con be pulled out straight.

9. Place both thread ends under the slot of the presser foot and draw toward the bock of the machine, leaving both threads three or four inches long.

White 616 Sewing Machine Threading Instructions

You can find the complete instruction manual here.

Singer 2932 Sewing Machine Threading Instructions.







Threading Instructions

* Start by raising the needle to its highest point (1 ), and also raise the presser foot to release the tension discs.
Note: For safety, it is strongly suggested you turn off the power before threading.

Lift up the spool pin. Place the spool of thread on the holder with the thread coming off the spool as shown. For small thread spools, place small side of spool holder next to spool. (3)

Draw thread from spool through the upper thread guide. (4)

Guide thread around thread guide (5) pulling thread through pre-tension spring as illustrated.

Thread tension module by leading thread down right channel and up left channel (6). During this process it is helpful to hold
the thread between the spool and thread guide (4)

At the top of this movement pass thread from right to left through the slotted eye of the take-up lever and then downwards again.

Pass thread behind the flat, horizontal thread guide. (8)

Now take thread behind the thin wire needle clamp guide and then down to the needle which should be threaded from front to back. Pull about 6-8 inches of thread to the rear beyond
the needle eye. (9)

NOTE* If your sewing machine is equipped with the factory installed optional automatic needle threader, instructions for use can be found on page 26.

Singer 2932 Sewing Machine Threading Instructions

You can find the complete instruction manual here.

Janome 5024 Sewing Machine Threading Instructions.

Decor Excel ll







Threading Instructions

* Raise the presser foot lifter.
* Press the up/down needle position button twice to raise the needle.

1) Lead the thread from the spool and pass it through the thread guide. Then draw it down along the right slot.

2) Then, down around the check spring holder.

3) Firmly draw the thread from right to left over the take-up lever and down into the take-up lever eye.

4) Slide the thread behind the needle bar thread guide on the left.
Thread the needle from front to back or use the needle threader.

Janome 5024 Sewing Machine Threading Instructions

You can find the complete instruction manual here.

Singer 319 Sewing Machine Threading Instructions.







Threading Instructions

Raise take-up lever 5 to its highest point.

Place thread on spool pin and hold with right hand.

Lead thread into self-threading guide 1 from under side,
Down and from right to left behind or in front of center
tension disc 2 (Center disc separates threads for twin needle sewing.)
Into the loop of the take-up spring 3,
Under the slack thread regulator 4,
Up and from right to left through hole in take-up lever 5,
Down through guides 6 and 7 on face plate,
Into guide 8 on needle clamp,
From front to hack through eye of needle 9.

Draw about two inches of thread through eye of needle with which to start sewing.

Note: You may want to cut the end of thread with sharp scissors for easier needle threading.

Singer 319 Sewing Machine Threading Instructions.

Swing needle automatic.

You can find the complete instruction manual here.
